I rebuilt an existing interface module — to be a stand-alone temperature and humidity sensor, with serial RS-232 interface. Uses an AVR ATmega8 microcontroller.
Temperature and light sensor with signalling LEDs (RS-232), AVR
I rebuilt an existing interface module — to be a stand-alone temperature and light sensor, with serial RS-232 interface and some signal LEDs. Uses an AVR ATmega8 microcontroller.
Portable alarm system (school project, electronics)
Portal alarm box unit, my main project on technical college.
Serial interface module, with analog and digital I/O — AVR
Serial (RS-232) interface module; providing 6 analog and 2 digital inputs, and 9 digital outputs. Uses an AVR ATmega8 microcontroller.
Serial port I/O module with 15 inputs — AVR
Serial (RS-232) interface module; providing 15 digital inputs. Uses an AVR ATmega8 microcontroller.
Serial interface for emergency power off — AVR
RS-232 interface module, with voltage measurement. Used to communicate with the emergency power off unit in the Rack box project. Installed inside Rack box status panel. Uses an AVR ATmega8 microcontroller.
Serial port I/O module with 9 in and outputs — AVR
RS-232 interface module, with 9 inputs and 9 outputs. Uses an AVR ATmega8 microcontroller.
Home power consumption measuring unit, with AVR
Measures the power consumption by counting LED pulses from the home fuse box. Measurements can be read via a serial interface, uses the AVR ATtiny2313 microcontroller.
Serial port I/O module with 11 inputs — AVR
RS-232 input module, with 11 inputs. Rebuild of previous RS-485 module. Uses an AVR ATtiny2313 microcontroller.
